H7c Dual 2K⁺ Camera tầm nhìn bao quát hơn cho sự bảo vệ toàn diện và thông minh hơn với ống kính kép
Độ phân giải camera 2MP
Camera góc rộng 146 độ
Màn hình cảm ứng 4.3 inch
Điều khiển qua ứng dụng EZVIZ
Kết nối wifi 2.4G
Specifications | |
---|---|
Model | CS-HP2-R100-6E2WB-GD, CS-HP2-R100-6E2WB-GR |
Installation Parameters | |
Supportive Hole Diameter | 14 to 26 mm (0.55 to 1.0 inch) |
Supportive Door Diameter | 35 to 105 mm (1.38 to 4.13 inch) |
Camera Parameters | |
Sensor | 1/3" Progressive Scan CMOS |
Lens | 2.0 mm @ F1.6, visual angle (diagonal):146° |
Max. Resolution | 1080p / 2MP |
Video Frame Rate | 15fps |
Interface | |
Buttons | 1. Screen Wake-up Button (Reset button) 2. On/off Button |
Network | |
Protocol | EZVIZ Cloud Proprietary Protocol |
Video Viewing | Local and remote video Viewing |
General Function | Cloud video encryption and image encryption |
Wireless | |
Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth | Supports 20 MHz |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps |
General | |
Screen | 4.3-inch color screen |
Color | Silver/Golden |
Operating Conditions | -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
Power Supply | DC 5V (±10%) |
Power Consumption | Max. 2W |
Dimension | Screen: 113*75*20 mm (4.45*2.95*0.97 inch) |
Peephole: 32 mm Diameter (1.26 inch Diameter) | |
Weight | 190g (6.7oz) |
In the box | |
In the box | - Camera |
- Panel | |
- Mounting Base | |
- Power Cable | |
- Screws × 8 | |
- Regulatory Information ×2 | |
- Quick Start Guide | |
Certifications | |
Certifications | CE / WEEE / ROHS / REACH |
